POLYTONE®

Phenolic Resin -Reinforcing

About Polytone® AP Series Reinforcing

POLYTONE® AP Reinforcing Resins are usually used in conjugation with methylene donor like Hexa. Most wide use in in the apex of tires or in rubber compounds which require hardness. POLYTONE® AP 130/131/133 are manufactured using modified phenols to provide required property.

POLYTONE® AP 131 is particularly suited for industrial tread Applications such as farm, off the road, mining and truck tires. Tread compounds with 5-10 PHR of AP 131 cross linked with a methylene donor shall have excellent cut and chip resistance along with excellent abrasion resistance and high hardness.

POLYTONE® Resins which are on unmodified phenols provides higher hardness compared to other products. They are designed to give a consistent performance as a reinforcing resin in synthetic and natural rubber-based goods that require high hardness, excellent chip and abrasion resistance when cross linked with a methylene donor. There are used as a reinforcing resin in tire beads, shoe soles, apex strips and co-extruded window profiles.

POLYTONE® PF 132 can be used as an epoxy-phenolic co reactant in wide range of epoxy co reactant applications like laminates, adhesives and coatings. POLYTONE® PF 132 can also be used in varnishes, insulations, inks and coatings.

POLYTONE® PF 425 and POLYTONE® PF 420 are Non Heat Reactive/Thermoplastic Phenol –Formaldehyde Novolak Resins POLYTONE® PF 420 is a high purity Non Heat Reactive/Thermoplastic Phenol – Formaldehyde Novolak Resin with low softening point.

Type

Non Heat Reactive

Thermoplastic

Reinforcing

Chemistry : POLYTONE® AP 130

Alkyl Phenol Formaldehyde

PtBP Resin/Butyl Phenol

Para Tert Butyl Phenol Resin

Chemistry : POLYTONE® AP 131

Alkyl Phenol Formaldehye

Phenol-POP Resin

Phenol-Octyl Phenol

Chemistry: POLYTONE® AP 132/ 1321/PF 132/PF 420/PF 425

Phenol Formaldehdye

Unmodified Phenolic Novolak

Phenolic Resin Type

Novolak

POLYTONE®   Butyl Curing Tackifier Reinforcement
AP 113 PtOP Resol
AP 113 A PtOP Resol
AP 120 PtBP Novolak
AP 120 H PtBP Novolak
AP 120 E PtBP Novolak
AP 1201 E PtBP Novolak
AP 121 PtBP Novolak
AP 121 H PtBP Novolak
AP 130 Mod.Phenol Novolak
AP 131 Mod.Phenol Novolak
AP 132 PF Novolak
AP 1321 PF Novolak
AP 133 Mod.Phenol Novolak
PF 132 PF Novolak
PF 420 PF Novolak
PF 425 PF Novolak
PF 200 2 Part PF Novolak
PF 201 2 Part PF Novolak

Properties

Product Name POLYTONE® Thermoplastic Methylene Donor Required Alkyl Phenol Based Pure Phenol Based
AP 130
AP 131
AP 132
AP 1321
AP 133
PF 132
PF 420/425
PF 200/201 2 Component     ✔ + Catalyst

Reinforcing Resins – Modified Phenol Based

POLYTONE® AP Reinforcing Resins are usually used in conjugation with methylene donor like Hexa. Most wide use in in the apex of tires or in rubber compounds which require hardness.

POLYTONE® AP 130/131/133 are manufactured using modified phenols to provide required property.

POLYTONE® AP 131 is particularly suited for industrial tread Applications such as farm, off the road, mining and truck tires. Tread compounds with 5-10 PHR of AP 131 cross linked with a methylene donor shall have excellent cut and chip resistance along with excellent abrasion resistance and high hardness.

Rubber Reinforcing

  POLYTONE® AP 130 POLYTONE® AP 131 POLYTONE® AP 133
Chemical Classification Butyl Phenol (PtBP) Formaldehyde Novolak Resin Phenol – Octyl Phenol (PtOP) Formaldehyde Novolak Resin Phenol -Butyl Phenol (PtBP) Formaldehyde Novolak Resin
Type Non Heat Reactive /Thermoplastic Non Heat Reactive /Thermoplastic Non Heat Reactive /Thermoplastic
Colour Pale Yellow/light Reddish Brown Pale Yellow/light Reddish Brown Pale Amber
Softening Point (Ball & Ring) 90 – 103 °C 90 – 105 °C 100 – 110 °C
Methylol Content - 1.0% Max -
Acid Value 45 mg KOH/ g resin (Max) 45 mg KOH/ g resin (Max) 45 mg KOH/ g resin (Max)
Free Phenol 1.0% Max 1.0% Max 0.50% Max
Ash Content 1.0% Max 1.0% Max 0.02% Max [@850°C]
Characteristics
  • Reinforces Compounds with Synthetic & Natural Rubbers
  • Suited for Tire Beads
  • Chip Resistance
  • Abrasion Resistance
Solubility Soluble in esters, ketones, aromatic and aliphatic chlorinated hydrocarbons. Insoluble in higehr alcohols
Application/Industry Used as a reinforcing resin in tire beads, shoe soles, apex strips and co-extruded window profiles.
Tyre /Tire Building, Conveyor Belts, Rubber Hose, Rubber Lining, Shoe Soles, Apex Strips, Tire Beads, Tire Treads, Rubber Mats, Rubber Sheets, Reinforced Rubber, Fabric Lined Rubber, Rubber Adhesives, Rubber Goods and many more.
*Test Methods available on request

Reinforcing Resins – Pure/Unmodified Phenol Based

POLYTONE® Resins which are on unmodified phenols provides higher hardness compared to other products They are designed to give a consistent performance as a reinforcing resin in synthetic and natural rubber based goods that require high hardness, excellent chip and abrasion resistance when cross linked with a methylene donor. There are used as a reinforcing resin in tire beads, shoe soles, apex strips and co-extruded window profiles .

POLYTONE® PF 132 can be used as an epoxy-phenolic co reactant in wide range of epoxy co reactant applications like laminates, adhesives and coatings .

POLYTONE® PF 132 can also be used in varnishes, insulations, inks and coatings.

POLYTONE® PF 425 and POLYTONE® PF 420 are Non Heat Reactive/Thermoplastic Phenol –Formaldehyde Novolak Resins
POLYTONE® PF 420 is a high purity Non Heat Reactive/Thermoplastic Phenol – Formaldehyde Novolak Resin with low softening point.

Rubber Reinforcing/Epoxy CO Reactant

  POLYTONE® AP 132 POLYTONE® AP 1321 POLYTONE® PF 132
Chemical Classification Phenol Formaldehyde Resin (Novolak) Phenol Formaldehyde Resin (Novolak) Phenol Formaldehyde Resin (Novolak)
Type Non Heat Reactive /Thermoplastic Non Heat Reactive /Thermoplastic Non Heat Reactive /Thermoplastic
Colour Pale Yellow/light Reddish Brown Pale Yellow/light Reddish Brown Pale Yellow/light Reddish Brown
Softening Point (Ball & Ring) 110 – 116 °C 90 – 100 °C 100 – 116 °C
Methylol Content - 1.0% Max -
Free Phenol 1.0% Max 1.0% Max 0.50% Max
Ash Content 1.0% Max 1.0% Max 0.02% Max [@850°C]
Characteristics
  • Reinforces Compounds with Synthetic & Natural Rubbers
  • Suited for Tire Beads
  • Chip Resistance
  • Abrasion Resistance
Solubility Soluble in esters, ketones, aromatic and aliphatic chlorinated hydrocarbons. Insoluble in higehr alcohols
Application/Industry Used as a reinforcing resin in tire beads, shoe soles, apex strips and co-extruded window profiles.
Tyre /Tire Building, Conveyor Belts, Rubber Hose, Rubber Lining, Shoe Soles, Apex Strips, Tire Beads, Tire Treads, Rubber Mats, Rubber Sheets, Reinforced Rubber, Fabric Lined Rubber, Rubber Adhesives, Rubber Goods and many more.
Can be used as an epoxy-phenolic co reactant in wide range of epoxy co reactant applications like laminates, adhesives and coatings Can also be used in varnishes, insulations, inks and coatings
*Test Methods available on request

Reinforcing/Epoxy CO Reactant

  POLYTONE® PF 425 POLYTONE® PF 420
Chemical Classification Phenol Formaldehyde Resin (Novolak) Phenol Formaldehyde Resin (Novolak)
Type Non Heat Reactive /Thermoplastic Non Heat Reactive /Thermoplastic
Colour Pale Yellow/Light Reddish Brown Pale Yellow/Light Reddish Brown
Softening Point (Ball & Ring) 110 – 120 °C 80 – 90 °C
Free Phenol 5% 2%
Characteristics
  • Reinforces Compounds with Synthetic & Natural Rubbers
  • Chip Resistance
  • Abrasion Resistance
Solubility POLYTONE® PF 425/420 is soluble in alcohols, esters, ketones, aromatic and aliphatic chlorinated hydrocarbons.
Application/Industry Tyre /Tire Building, Conveyor Belts, Rubber Hose, Rubber Lining, Rubber Mats, Rubber Sheets, Reinforced Rubber, Fabric Lined Rubber, Rubber Adhesives.
POLYTONE® PF 425 and POLYTONE® PF 420 can be used as an epoxy-phenolic co reactant in wide range of epoxy co-reactant applications like laminates, adhesives and coatings
POLYTONE® PF 425 and POLYTONE® PF 420 can also be used in varnishes and inks
*Test Methods available on request

Reinforcing Resins – 2 Component/ Methylene Donor Based

  POLYTONE® PF 200 POLYTONE® PF 201
Chemical Classification Phenol Formaldehyde Resin with Hexa Phenol Formaldehyde Resin with Hexa
Type Heat Reactive/2 Step mixed with Hexa Heat Reactive/2 Step mixed with Hexa
Colour Cremish Yellow Cremish Yellow
Melting Point (Capillary) 75° C – 90 ° C 70° C – 85 ° C
Inclined Plate Flow @ 125° C 30 – 35mm 30 – 45mm
Hot Plate Cure @ 150° C 75 – 100 seconds 40 – 65 seconds
Sieve Analysis (200 Mesh) 90 - 95% Min 96 – 99% Min
Hexa Content 9 – 10 % 7.5 – 8.5 %
Characteristics
  • Reinforces Compounds with Synthetic & Natural Rubbers
  • Chip Resistance
  • Abrasion Resistance
Solubility POLYTONE® PF 200/201 is soluble in alcohols, esters, ketones, aromatic and aliphatic chlorinated hydrocarbons.
Application/Industry Tires and technical rubber goods use straight phenolic novolac resins as reinforcing agents.
Abrasives, Emry Wheels, Composites, Refractory, Cured phenolic resins demonstrate exceptional chemical resistance as coatings
*Test Methods available on request

Effect on Formulation

Product Name POLYTONE® Hardness & Chip Resistance Suitability for Tire Beads & Treds Reinforcing Processing Temperature
AP 130 ★★★ ★★★ ★★★★ ★★★★
AP 131 ★★★ ★★★ ★★★★ ★★★★
AP 132 ★★★★★ ★★★★★ ★★★★★ ★★★
AP 1321 ★★★★★ ★★★★★ ★★★★★ ★★★
AP 133 ★★★ ★★★★ ★★★ ★★★
PF 132 ★★★★★ ★★★★★ ★★★★★ ★★★
PF 420/425 ★★★★ ★★ ★★★★ ★★★★
  • These resin in presence of catalyst become “Thermoset”.
  • They provide “plasticizing effect” while processing.
  • They increase “Shore Hardness” of Rubber Compound.
  • They provide Hardness, Chip Resistance, Abrasion Resistance.

Solubility

  POLYTONE® PF Series POLYTONE® PF Series
Alcohols
Higher Alcohols
Ketones
Esters
Aromatic Hydrocarbons
Chlorinated Hydrocarbons
Aliphatic Hydrocarbon
Oil

Soluble

Limited Solublility

Insoluble

Compatibility

  POLYTONE® PF Series
SBR
SBR-BR Blends
Natural Rubber
Nitrile Rubber

Fully Compatible

Limited Compatibility

Not Compatible

Typical Uses

Product Name POLYTONE® Rubber & Tire Epoxy CO Reactant Abrasives & Emery Paints & Inks
AP 130 ★★★★ - - ★★★
AP 131 ★★★★ - - ★★★
AP 132 ★★★★★ ★★ ★★ ★★★★
AP 1321 ★★★★★ ★★ ★★ ★★★★
AP 133 ★★★★★ - -
PF 132 ★★★★★ ★★★★★ ★★ ★★★
PF 420/425 ★★ ★★★★★ ★★ ★★★
PF 200/201 ★★★★ - ★★★★★ -
★★★★★ :Excellent ★★★★: Good ★★★:Fair ★★: Moderate ★: Poor
  • Available in 25Kg HDPE Line KRAFT Paper Bags with Anti-Static Liner or 25Kg HDPE Bags
  • Choice of ISPM 15 Standard Heat Treated/Fumigated Pallets or Plastic Pallets.
  • Individual pallets must NOT be double stacked – pastilles/lumps are likely to agglutinate.
  • Properties are not affected by agglutination.
  • Phenolic Resins tend to discolor over time.
  • Can be stored up to 12 months at temperatures below 35 °C.

Please follow advice and information provided in MSDS. Protective clothing & workplace hygiene measure must be observed at all times.

Detailed MSDS available on request.
